FD 60W Solar panel
The FD 60 is a 60W foldable solar panel packing high-efficiency monocrystalline cells into a 2.8 kg weatherproof briefcase, delivering up to 3.33 A at 18 V—perfect for camping, hiking, RVs, and emergency backup. Lightweight yet durable, it is designed for outdoor enthusiasts who need reliable clean energy on the go.
High-Efficiency Monocrystalline Cells (≥ 20%)
Ultra-Lightweight & Compact (2.8 kg)
Rugged, Weather-Resistant Build
Plug-and-Play Anderson 30A Connector
Rapid Deployment in Seconds
Peak Power: 60 W
Open-Circuit Voltage (VOC): 21.6 V
Maximum Power Voltage (VMP): 18 V
Maximum Power Current (IMP): 3.33 A
Short-Circuit Current (ISC): 3.75 A
Cell Efficiency: ≥ 20 %
Folded Size: 350 × 315 × 40 mm
Unfolded Size: 1360 × 350 × 10 mm
Weight: 2.8 kg
Connector: 2 × 1.0 mm² cable, 1.5 m Anderson 30 A
High-Efficiency A-Grade Monocrystalline Cells
Rugged Composite Construction
Drop-Impact Resistance
Waterproof Fabric Housing
Plug-and-Play Connector
MC4 Extension Cables (1 m, 2 m, 5 m lengths)
MC4 Y-Branch Connectors for parallel string configurations
10~15 years
- Download Datasheet
- Installation Video Tutorial (YouTube/Embedded Player)
- User Manual
- FAQ
Product Introduction
Our FD 60W delivers 60 W peak power from four A-grade monocrystalline cells (≥ 20 % efficiency at STC) and provides up to 3.33 A charging current at 18 V for 12–14 V battery systems—even in extreme temperatures (−40 °C to 85 °C). With its lightweight 2.8 kg foldable design, it is perfect for camping, hiking, and emergency backup.
Rugged, Weatherproof Construction
Frosted PET front sheet and FR-4 fiberglass backplane are laminated into a waterproof, abrasion-resistant fabric housing. Sealed edges survive 1 m drops and heavy rain, ensuring over 10 years of reliable outdoor operation.
Effortless Portability & Tool-Free Setup
Folds compact to 330 × 505 × 40 mm and weighs just 4 kg. Built-in handle, adjustable straps, and reinforced buckles let you carry it like a briefcase or hang it on tents, poles, or RV rails. No tools required—unfold, angle toward the sun, plug in, and start charging within seconds.
Technical Data
| PARAMETER | SPECIFICATION |
|---|---|
| Model | FD 60 |
| Peak Power | 60W |
| Open-circuit Voltage | 21.6V |
| Max. Voltage | 18V |
| Max. Current | 3.33A |
| Short-circuit Current | 3.75A |
| Solar Cell Efficiency | 20% |
| Solar Panel Connections | 15W / 18V × 4 pcs in parallel connection |
| Folded Size | 350 × 315 × 40 mm |
| Unfolded Size | 1360 × 350 × 10 mm |
| Weight | 2.8 kg |
| Solar Cell | A grade |
| Front Cover Material | PET (Frosted surface) |
| Back Board | FR-4 Fiberglass board |
| Cable / Connector | 2 × 1.0 mm² / 1.5M Anderson connector (30A) |
| Tension Limit | 150N |
| Grade | A |
| NOCT | 48 ± 2 ℃ |
| Operating Temperature | -40 ℃ to +85 ℃ |
| Temperature Coefficient (Current) | 0.1% / ℃ |
| Temperature Coefficient (Voltage) | -0.37% / ℃ |
| Temperature Coefficient (Power) | -0.45% / ℃ |
| STC Conditions | Irradiance: 1000 W/m²; Cell temperature: 25℃; AM1.5 |
